Features and Benefit

•  Mattress area divided into 4 sections made up of ABS top.
•  Detachable Polymer Molded head and foot bows provide a soothing look.
•  Provided with four sectional polymer molded safety side rails with angle indicators.
•  Major Features include: Backrest, Knee rest, Trendelenburg / Reverse Trendelenburg, Height Adjustment, Cardiac Chair Position, Zero Level Position maneuverable by four separate linear actuators which are operated through integrated panels on Foot Boards and Upperside railings.
• Auto Regression on the backrest 10 cm for less stress on pelvic area.
• Dual Side Lever for Manual CPR.

Overall Dimension (when fully extended):

Overall Dimensions : 2300 mm L X 1000 mm W

Frame Size : 2060 mm L X 900 mm W

Mattress Platform : 1930mm LX 900mm W

Back rest tilt : 0-75 degree

Knee rest tilt : 0-35 degree

Trendelenburg/ Reverse Trendelenburg : 0-12 degree
